This machine is for hand towel product for high product, it will transfer the product directly to the packing machine, no need after -treatment device.
This machine is for hand towel product for high product, it will transfer the product directly to the packing machine, no need after -treatment device.
PRODUCTS PARAMETER
| No | Item | Technical parameters |
| 1 | Max jumbo roll width | 1450mm |
| 2 | Jumbo roll diameter | <=¢1500 |
| 3 | Release speed(m/min) | ＜110 |
| 4 | Inner core diameter | ￠76.3mm |
| 5 | Machine structure | Wall type frame |
| 6 | Jumbo roll weight（t） | Max 0.8 |
| 7 | Rewind stand system | Based band conveyor belt |
| 8 | Jumbo roll centralization | manual adjustment |
| 9 | Roll open type | clockwise |
| 10 | Jumbo roll web type | manual |
| 11 | Tissue Break detecting | with break tissue detecting system and will stop the machine to reduce the waste |
| 12 | Back wind power KW | 1.5x2=3KW |
| 13 | Min pressure requirement | 0.6Mpa |
| 14 | Air consumption | 1000lifter/shift |
| 15 | Stand transmission type | independent motor control |
| 16 | Loading type | cylinder uploading |
| 17 | Transmission | |
| 18 | Paper send belt | belt transmission |
| 19 | Paper width | Screw transmission |
| 20 | Other | |
| 21 | Protection | main transmission parts are protected by the safe guard |
